SXO75L3A481-156.250M,SUNTSU松圖晶振,7050差分晶振
頻率：40.000MHZ
尺寸：5032mm
SXO75L3A481-156.250M,SUNTSU松圖晶振,7050差分晶振
SUNTSU松圖SXO75L3A481-156.250M7050差分晶振,是松圖品牌專為高頻同步場景打造的高性能差分頻率元件.其標稱頻率精準設定為156.250MHz,采用行業標準7050封裝,尺寸緊湊可適配高密度晶振電路板布局.該晶振搭載差分輸出架構,能有效抑制共模干擾,輸出信號相位一致性強,同時具備優異的頻率穩定度與低相位噪聲特性,引腳兼容主流差分晶振設計,可直接滿足高速通信,FPGA/CPLD系統的核心頻率源需求,是工業級與高端消費電子設備的優質高頻解決方案.
SXO75L3A481-156.250M,SUNTSU松圖晶振,7050差分晶振
|
原廠型號 Originalmodel： |
SXO75L3A481-156.250M |
品牌brand： |
|
|
Manufacturer品牌 |
OperatingTemperature溫度 |
-40°C ~ 85°C |
|
|
Series型號 |
SXO75L |
Current-Supply(Max) |
- |
|
Type類型 |
SPXO |
PackageHeight高度 |
1.7mm |
|
Frequency頻率 |
156.250M |
Termination 腳位 |
6-pad |
|
輸出方式 Output： |
LVDS差分輸出 |
PackageType 封裝類型 |
6-Smd |
|
Voltage-Supply電壓 |
3.3V |
Packaging 包裝 |
TapeandReel |
|
FrequencyStability頻率穩定度 |
±50ppm |
安裝方式 Installation： |
Surfacemount |
|
Size/Dimension尺寸 |
7050MM |
最小包裝數MPQ： |
1000 |
SXO75L3A481-156.250M,SUNTSU松圖晶振,7050差分晶振
