About Raltron crystal in the United States

來源：金洛鑫瀏覽：- 發布日期：2023-12-28 16:59:58【大中小】

Founded in Miami, Fl. in 1983, Raltron Electronics Corporation has grown to become one of the most recognized and experienced manufacturers of frequency management products in the world. From simple tuning fork quartz crystals to high stability oven-controlled crystal oscillators, Raltron offers the most comprehensive line of frequency management devices in the industry.

The company’s commitment to research and development has allowed the continuous creation of leading edge crystal and oscillators devices and technologies over many years. Today, Raltron provides high performance frequency control solutions that meet and exceed customer expectations in terms of price, quality, application and customer support.

To satisfy the demands of the fast-growing wireless applications markets Raltron has also positioned itself as a complete solution supplier, adding SAW devices and LTCC filters to its crystals and oscillators offering. The company has also developed a complete product range of antennas for the same markets. Raltron is supporting its worldwide customers through a global network of independent Sales Representatives as well as several subsidiary offices in Asia, strategically located close to key customers and markets. The company’s products are distributed by several large global Distributors, by prominent high-service distributors as well as Regional Distributors addressing specific marketplaces. Raltron is developing and manufacturing precision oscillators in its Miami, Fl. facility while simple crystal resonators, clock oscillators and filters as well as antennas are produced in several facilities located in Asia. The company is shipping the products worldwide from its Hong Kong based logistics hub. All Raltron晶振 employees are committed to a continuing pursuit of quality and excellence. This philosophy has kept Raltron in a leadership position through years of uninterrupted growth. In depth technical support from the first steps of the customer’s product development process and continuing throughout the customer’s product life cycle is assured by two applications engineering teams based in Florida and in Asia. Both locations are also featuring Failure Analysis labs equipped with modern test equipment allowing the company to respond in real time to customers’solicitations.

Raltron is dedicated to continuous growth through investing a substantial part of its earnings for deepening existing customer relationships, penetrating new markets and developing cutting edge performance new products.

原廠編碼	型號	頻率	頻率穩定度	頻率容差	負載電荷	工作溫度
RT3215-32.768-12.5-TR	RT3215	32.768 kHz	-	±20ppm	12.5pF	-40°C ~ 85°C
RSM200S-32.768-12.5-TR	RSM200S	32.768 kHz	-	±20ppm	12.5pF	-40°C ~ 85°C
H130B-8.000-18-3030-EXT-TR	H130B	8 MHz	±30ppm	±30ppm	18pF	-40°C ~ 85°C
RSM200S-32.768-12.5-10PPM-NPB	RSM200S	32.768 kHz	-	±10ppm	12.5pF	-40°C ~ 85°C
AS-24.000-18-SMD-TR	AS-SMD	24 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
AS-6.000-12-2020-EXT-SMD-TR	AS-SMD	6 MHz	±20ppm	±20ppm	12pF	-40°C ~ 85°C
RH100-25.000-10-F-3030-EXT-TR	RH100	25 MHz	±30ppm	±30ppm	10pF	-40°C ~ 85°C
RH100-12.000-18-2020-EXT-TR	RH100	12 MHz	±20ppm	±20ppm	18pF	-40°C ~ 85°C
RH100-25.000-13-F-0715-EXT-TR-NS1	RH100	25 MHz	±15ppm	±7ppm	13pF	-40°C ~ 85°C
AS-16.000-18-SMD-TR	AS-SMD	16 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
AS-11.0592-18-SMD-TR	AS-SMD	11.0592 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
RH100-16.000-16-3030-EXT-TR	RH100	16 MHz	±30ppm	±30ppm	16pF	-40°C ~ 85°C
RH100-24.000-9-1015-EXT-TR	RH100	24 MHz	±15ppm	±10ppm	9pF	-40°C ~ 85°C
RH100-32.000-16-F-1015-EXT-TR	RH100	32 MHz	±15ppm	±10ppm	16pF	-40°C ~ 85°C
RH100-40.000-9-F-1010-EXT-TR	RH100	40 MHz	±10ppm	±10ppm	9pF	-40°C ~ 85°C
RH100-48.000-8-F-1015-EXT-TR	RH100	48 MHz	±15ppm	±10ppm	8pF	-40°C ~ 85°C
RH100-12.000-20-2030-TR	RH100	12 MHz	±30ppm	±20ppm	20pF	-20°C ~ 70°C
RH100-11.0592-18-3030-EXT-TR	RH100	11.0592 MHz	±30ppm	±30ppm	18pF	-40°C ~ 85°C
RH100-25.000-18-F-TR	RH100	25 MHz	±100ppm	±100ppm	18pF	-20°C ~ 70°C
RH100-26.000-10-F-1010-EXT-TR	RH100	26 MHz	±10ppm	±10ppm	10pF	-40°C ~ 85°C
RH100-12.000-12-1010-X-TR-NS2	RH100	12 MHz	±10ppm	±10ppm	12pF	-30°C ~ 85°C
RH100-25.000-18-F-2030-EXT-TR	RH100	25 MHz	±30ppm	±20ppm	18pF	-40°C ~ 85°C
RH100-48.000-10-F-1015-EXT-TR	RH100	48 MHz	±15ppm	±10ppm	10pF	-40°C ~ 85°C
R38-32.768-12.5	R38	32.768 kHz	-	±20ppm	12.5pF	-20°C ~ 70°C
R26-32.768-12.5	R26	32.768 kHz	-	±20ppm	12.5pF	-40°C ~ 85°C
RH100-12.000-20-3030-EXT-TR	RH100	12 MHz	±30ppm	±30ppm	20pF	-40°C ~ 85°C
RH100-12.000-18-2020-TR	RH100	12 MHz	±20ppm	±20ppm	18pF	-20°C ~ 70°C
RH100-24.000-18-2030-EXT-TR	RH100	24 MHz	±30ppm	±20ppm	18pF	-40°C ~ 85°C
RH100-12.000-12-1010-EXT-TR	RH100	12 MHz	±10ppm	±10ppm	12pF	-40°C ~ 85°C
RH100-12.000-9-1015-TR-NS1	RH100	12 MHz	±15ppm	±10ppm	9pF	-20°C ~ 70°C
RH100-25.000-16-F-2020-EXT-TR	RH100	25 MHz	±20ppm	±20ppm	16pF	-40°C ~ 85°C
RH100-24.000-8-1010-EXT-TR	RH100	24 MHz	±10ppm	±10ppm	8pF	-40°C ~ 85°C
RH100-25.000-18-F-1010-TR	RH100	25 MHz	±10ppm	±10ppm	18pF	-20°C ~ 70°C
RH100-16.000-8-1010-TR	RH100	16 MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
RH100-25.000-10-F-1010-EXT-TR	RH100	25 MHz	±10ppm	±10ppm	10pF	-40°C ~ 85°C
R2520-32.000-8-F-1030-EXT-TR	R2520	32 MHz	±30ppm	±10ppm	8pF	-40°C ~ 85°C
AS-3.579545-18	AS	3.579545 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
AS-4.000-18	AS	4 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
AS-20.000-20	AS	20 MHz	±50ppm	±30ppm	20pF	-20°C ~ 70°C
AS-11.0592-18-EXT	AS	11.0592 MHz	±50ppm	±30ppm	18pF	-40°C ~ 85°C
AS-16.000-20-EXT	AS	16 MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
AS-27.000-20-F	AS	27 MHz	±50ppm	±30ppm	20pF	-20°C ~ 70°C
AS-25.000-18-F-EXT	AS	25 MHz	±50ppm	±30ppm	18pF	-40°C ~ 85°C
R2520-12.000-8-1030-EXT-TR	R2520	12 MHz	±30ppm	±10ppm	8pF	-40°C ~ 85°C
RT3215-32.768-9-TR	RT3215	32.768 kHz	-	±20ppm	9pF	-40°C ~ 85°C
RSM200S-32.768-6-TR	RSM200S	32.768 kHz	-	±20ppm	6pF	-40°C ~ 85°C
H130B-16.000-18-3030-EXT-TR	H130B	16 MHz	±30ppm	±30ppm	18pF	-40°C ~ 85°C
H130B-12.000-18-3030-TR	H130B	12 MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
H130B-24.000-18-3030-EXT-TR	H130B	24 MHz	±30ppm	±30ppm	18pF	-40°C ~ 85°C
RSE-32.768-12.5-H14-TR	RSE H14	32.768 kHz	-	±50ppm	12.5pF	-20°C ~ 70°C
RH100-8.000-10-1010-EXT-TR	RH100	8 MHz	±10ppm	±10ppm	10pF	-40°C ~ 85°C
H130A-8.000-8-2030-TR	H130A	8 MHz	±30ppm	±20ppm	8pF	-20°C ~ 70°C
RH100-8.000-8-2020-TR	RH100	8 MHz	±20ppm	±20ppm	8pF	-20°C ~ 70°C
RT2012-32.768-6-TR	RT2012	32.768 kHz	-	±50ppm	6pF	-40°C ~ 85°C
RH100-8.000-16-3030-TR-NS1	RH100	8 MHz	±30ppm	±30ppm	16pF	-20°C ~ 70°C
H13-8.000-18-3030-EXT-TR	H13	8 MHz	±30ppm	±30ppm	18pF	-40°C ~ 85°C
AS-4.9152-18-EXT-SMD-TR	AS-SMD	4.9152 MHz	±50ppm	±30ppm	18pF	-40°C ~ 85°C
AS-10.000-20-3030-SMD-TR	AS-SMD	10 MHz	±30ppm	±30ppm	20pF	-20°C ~ 70°C
AS-30.000-10-F-2020-EXT-SMD-TR	AS-SMD	30 MHz	±20ppm	±20ppm	10pF	-40°C ~ 85°C
AS-4.000-18-SMD-TR	AS-SMD	4 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
AS-3.579545-18-SMD-TR	AS-SMD	3.579545 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
AS-13.560-20-SMD-TR	AS-SMD	13.56 MHz	±50ppm	±30ppm	20pF	-20°C ~ 70°C
AS-20.000-16-SMD-TR	AS-SMD	20 MHz	±50ppm	±30ppm	16pF	-20°C ~ 70°C
AS-7.3728-20-EXT-SMD-TR	AS-SMD	7.3728 MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
AS-7.3728-18-SMD-TR	AS-SMD	7.3728 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
RH100-13.560-10-1020-EXT-TR	RH100	13.56 MHz	±20ppm	±10ppm	10pF	-40°C ~ 85°C
RH100-26.000-18-F-2030-EXT-TR	RH100	26 MHz	±30ppm	±20ppm	18pF	-40°C ~ 85°C
RH100-24.000-9-1010-TR	RH100	24 MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
RH100-24.000-8-1530-EXT-TR	RH100	24 MHz	±30ppm	±15ppm	8pF	-40°C ~ 85°C
RH100-10.000-10-5050-TR	RH100	10 MHz	±50ppm	±50ppm	10pF	-20°C ~ 70°C
RH100-10.000-8-2020-TR	RH100	10 MHz	±20ppm	±20ppm	8pF	-20°C ~ 70°C
RH100-24.000-20-3050-EXT-TR	RH100	24 MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
RH100-32.000-12-F-3030-TR	RH100	32 MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
RH100-50.000-12-F-1010-TR	RH100	50 MHz	±10ppm	±10ppm	12pF	-20°C ~ 70°C
RH100-50.000-10-F-1015-EXT-TR	RH100	50 MHz	±15ppm	±10ppm	10pF	-40°C ~ 85°C
RH100-16.000-9-1010-TR	RH100	16 MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
RH100-25.000-6-F-1010-TR	RH100	25 MHz	±10ppm	±10ppm	6pF	-20°C ~ 70°C
RH100-25.000-8-F-1010-TR	RH100	25 MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
RH100-26.000-12-F-1010-EXT-TR	RH100	26 MHz	±10ppm	±10ppm	12pF	-40°C ~ 85°C
RH100-32.000-10-F-1010-TR	RH100	32 MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
AS-8.000-20-SMD-TR	AS-SMD	8 MHz	±50ppm	±30ppm	20pF	-20°C ~ 70°C
R2520-32.000-10-F-1010-TR-B1B	R2520	32 MHz	±10ppm	±10ppm	10pF	-10°C ~ 60°C
AS-18.432-20	AS	18.432 MHz	±50ppm	±30ppm	20pF	-20°C ~ 70°C
R2520-24.000-10-1010-TR-NS4	R2520	24 MHz	±10ppm	±10ppm	10pF	-10°C ~ 60°C
RT3215-32.768-7-TR	RT3215	32.768 kHz	-	±20ppm	7pF	-40°C ~ 85°C
RH100-8.000-20-3050-EXT-TR	RH100	8 MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
R2016-32.000-10-F-1020-EXT-TR	R2016	32 MHz	±20ppm	±10ppm	10pF	-40°C ~ 85°C
R2016-32.000-12-F-1010-EXT-TR	R2016	32 MHz	±10ppm	±10ppm	12pF	-40°C ~ 85°C
R2016-32.000-10-F-1010-TR-B1B_REVB	R2016	32 MHz	±10ppm	±10ppm	10pF	-30°C ~ 70°C
H130B-25.000-12-F-EXT-TR	H130B	25 MHz	±50ppm	±50ppm	12pF	-40°C ~ 85°C
H130B-25.000-20-F-3030-TR	H130B	25 MHz	±30ppm	±30ppm	20pF	-20°C ~ 70°C
H130B-18.432-18-EXT-TR	H130B	18.432 MHz	±50ppm	±50ppm	18pF	-40°C ~ 85°C
R2016-27.120-10-F-1010-TR-NS4	R2016	27.12 MHz	±10ppm	±10ppm	10pF	-10°C ~ 60°C
H130A-24.000-18-2030-EXT-TR	H130A	24 MHz	±30ppm	±20ppm	18pF	-40°C ~ 85°C
RT2012-32.768-12.5-EXT-TR	RT2012	32.768 kHz	-	±50ppm	12.5pF	-40°C ~ 85°C
RT2012-32.768-7-20-EXT-TR	RT2012	32.768 kHz	-	±20ppm	7pF	-40°C ~ 85°C
H130B-50.000-16-F-1010-TR	H130B	50 MHz	±10ppm	±10ppm	16pF	-10°C ~ 60°C
RT2012-32.768-9-20-EXT-TR	RT2012	32.768 kHz	-	±20ppm	9pF	-40°C ~ 85°C
RT2012-32.768-9-TR	RT2012	32.768 kHz	-	±50ppm	9pF	-40°C ~ 85°C
RT3215-32.768-6-TR	RT3215	32.768 kHz	-	±20ppm	6pF	-40°C ~ 85°C
RSE-32.768-12.5-H14-TR-10PPM	RSE H14	32.768 kHz	-	±10ppm	12.5pF	-40°C ~ 85°C
RSE-32.768-6-H14-TR	RSE H14	32.768 kHz	-	±50ppm	6pF	-20°C ~ 70°C
H13-6.000-16-5050-EXT-TR	H13	6 MHz	±50ppm	±50ppm	16pF	-30°C ~ 85°C
AS-27.000-20-F-3030-SMD-TR	AS-SMD	27 MHz	±30ppm	±30ppm	20pF	-20°C ~ 70°C
AS-24.576-18-F-SMD-TR	AS-SMD	24.576 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
RH100-48.000-18-F-3030-TR	RH100	48 MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
R2520-26.000-9-F-1010-TR	R2520	26 MHz	±10ppm	±10ppm	9pF	-10°C ~ 60°C
R2016-16.000-9-1010-TR-NS1	R2016	16 MHz	±10ppm	±10ppm	9pF	-10°C ~ 60°C
RSE-32.768-7-H14-TR	RSE H14	32.768 kHz	-	±50ppm	7pF	-20°C ~ 70°C
RT1210-32.768-9-TR	RT1210	32.768 kHz	-	±20ppm	9pF	-40°C ~ 85°C
AS-5.000-18-EXT-SMD-TR	AS-SMD	5 MHz	±50ppm	±30ppm	18pF	-40°C ~ 85°C
RH100-26.000-9-F-1015-X-TR-NS2	RH100	26 MHz	±15ppm	±10ppm	9pF	-40°C ~ 85°C
RH100-24.000-12-1020-EXT-TR-N1	RH100	24 MHz	±20ppm	±10ppm	12pF	-40°C ~ 85°C
RH100-38.400-15-F-2030-EXT-TR-NS1	RH100	38.4 MHz	±30ppm	±20ppm	15pF	-40°C ~ 85°C
RH100-27.120-18-F-3030-EXT-TR	RH100	27.12 MHz	±30ppm	±30ppm	18pF	-40°C ~ 85°C
RH100-40.000-6-F-1010-EXT-TR	RH100	40 MHz	±10ppm	±10ppm	6pF	-40°C ~ 85°C
RH100-30.000-10-F-1010-TR	RH100	30 MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
RH100-25.000-20-F-1010-TR	RH100	25 MHz	±10ppm	±10ppm	20pF	-20°C ~ 70°C
RH100-32.000-9-F-1010-TR	RH100	32 MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
RH100-19.200-10-1010-TR-NS1	RH100	19.2 MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
RH100-12.000-9-1515-TR	RH100	12 MHz	±15ppm	±15ppm	9pF	-20°C ~ 70°C
RH100-20.000-10-1010-TR	RH100	20 MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
RH100-27.000-10-F-1010-TR-NS2	RH100	27 MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
RH100-38.400-8.5-F-1010-TR-NS2	RH100	38.4 MHz	±10ppm	±10ppm	8.5pF	-20°C ~ 75°C
AS-24.576-20-F-3030-SMD-TR	AS-SMD	24.576 MHz	±30ppm	±30ppm	20pF	-20°C ~ 70°C
AS-3.6864-18-SMD-TR	AS-SMD	3.6864 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
